• Model : P-01
    Part : P.P. Thread Foot Valve

    Foot Valve Flap Type

    Model : P-01

    Foot Valve

    Part Description Standard Material
    Part Name P.P. Thread Foot Valve
    Nominal Sizes 1/2",3/4",1",1.25",1.5",2",2.5",3",4"
    Body / Stranier Virgin Polypropelene Polymer
    Washer Thermo Plastic Elastomer
    Colour As Actual Orange
    Standard IS : 10805
    End Connections Screwed End Conforming to IS : 554
    Pressure Testing 0.02MPa to 0.5 Mpa
    Installation Vertical
  • Model : P-02
    Part : P.P. Thread Foot Valve S.T.

    Foot Valve Spring Type

    Model : P-02

    Foot Valve

    Part Description Standard Material
    Part Name P.P. Thread Foot Valve S.T.
    Nominal Sizes 1/2",3/4",1",1.25",1.5",2",2.5",3",4"
    Body / Stranier Virgin Polypropelene Polymer
    Washer Thermo Plastic Elastomer
    Colour As Actual Orange
    Spring SS 304
    End Connections Screwed End Conforming to IS : 554
    Installation Vertical
  • Model : P-03
    Part : P.P. Bolt Type Foot Valve

    Foot Valve B.T. Flap Type

    Model : P-03

    Foot Valve

    Part Description Standard Material
    Part Name P.P. Bolt Type Foot Valve
    Nominal Sizes 2",2.5",3",4",5",6"
    Body / Stranier Virgin Polypropelene Polymer
    Washer Thermo Plastic Elastomer
    Fastners Mild Steel
    Colour As Actual Orange
    Standard IS : 10805
    End Connections Screwed End Conforming to IS : 554
    Pressure Testing 0.02MPa to 0.5 Mpa
  • Model : P-04
    Part : P.P. Thread Foot Valve S.T.

    Foot Valve B.T. Spring Type

    Model : P-04

    Foot Valve

    Part Description Standard Material
    Part Name P.P. Thread Foot Valve S.T.
    Nominal Sizes 2",2.5",3",4"
    Body / Stranier Virgin Polypropelene Polymer
    Washer Thermo Plastic Elastomer
    Fastners Mild Steel
    Colour As Actual Orange
    Spring SS 304
    End Connections Screwed End Conforming to IS : 554
  • Model : P-07
    Part : P.P. Nipple Foot Valve

    Nipple Foot Valve F.T.

    Model : P-07

    Foot Valve

    Part Description Standard Material
    Part Name P.P. Nipple Foot Valve
    Nominal Sizes 1/2",3/4",1",1.25",1.5",2",2.5",3"
    Body / Stranier Virgin Polypropelene Polymer
    Washer Thermo Plastic Elastomer
    Colour As Actual Orange
    End Connections Nipple
    Installation Vertical
  • Model : P-08
    Part : P.P. Nipple Foot Valve S.T.

    Nipple Foot Valve S.T.

    Model : P-08

    Foot Valve

    Part Description Standard Material
    Part Name P.P. Nipple Foot Valve S.T.
    Nominal Sizes 1/2",3/4",1",2",2.5",3"
    Body / Stranier Virgin Polypropelene Polymer
    Washer Thermo Plastic Elastomer
    Colour As Actual Orange
    Spring SS 304
    End Connections Nipple
    Installation Vertical as well as horizontal
  • Model : C-01
    Part : Cast Iron Foot Valve (B.T.)

    Model : C-01

    Model : C-01

    Foot Valve

    Part Description Standard Material
    Part Name Cast Iron Foot Valve (B.T.)
    Nominal Sizes 2",2.5",3",4"
    Body / Stranier Cast Iron Conforming to IS : 210
    Washer Natural Rubber
    Fastners Mild Steel
    Standard IS : 10805
    End Connections Screwed End Conforming to IS : 554
    Pressure Testing 0.02MPa to 0.5 Mpa
    Installation Vertical
  • Model : C-03
    Part : Cast Iron Agro Foot Valve (K-3)

    Foot Valve Agro K-3

    Model : C-03

    Foot Valve

    Part Description Standard Material
    Part Name Cast Iron Agro Foot Valve (K-3)
    Nominal Sizes 2",2.5",3",4"
    Body / Stranier Cast Iron Conforming to IS : 210
    Washer Natural Rubber
    Fastners Mild Steel
    Installation Vertical
  • Model : C-05
    Part : Cast Iron Auto Foot Valve

    Foot Valve Spring Type

    Model : C-05

    Foot Valve

    Part Description Standard Material
    Part Name Cast Iron Auto Foot Valve
    Nominal Sizes 2",2.5",3"
    Body / Stranier Cast Iron Conforming to IS : 210
    Washer Natural Rubber
    Fastners Mild Steel
    Spring SS 304
    Installation Vertical
  • Model : P-05
    Part : Reflux Valve B.T. Flap Type

    Reflux Valve B.T. Flap Type

    Model : P-05

    Foot Valve

    Part Description Standard Material
    Part Name Reflux Valve B.T. Flap Type
    Nominal Sizes 2",2.5",3",4",8"
    Body / Stranier Virgin Polypropelene Polymer
    Washer Thermo Plastic Elastomer
    Fastners Mild Steel
    Colour As Actual Orange
    Standard IS : 10805
    End Connections Screwed End Conforming to IS : 554
    Pressure Testing 0.02MPa to 0.5 Mpa
    Installation Vertical
  • Model : P-06
    Part : Reflux Valve B.T. Spring Type

    Reflux Valve B.T. Spring Type

    Model : P-06

    Foot Valve

    Part Description Standard Material
    Part Name Reflux Valve B.T. Spring Type
    Nominal Sizes 2",2.5",3",4"
    Body / Stranier Virgin Polypropelene Polymer
    Washer Thermo Plastic Elastomer
    Fastners Mild Steel
    Colour As Actual Orange
    Spring SS 304
    End Connections Screwed End Conforming to IS : 554
